All specifications are measured at 14.4 Vdc (standard
automotive voltage).
Frequency Response: 10 Hz to 20 kHz + 1 dB
Total Harmonic Distortion (THD): 0.005%
Signal to Noise Ratio (SNR): 110 dB at full output
Maximum Output Level: 9.5 volts rms
Input Gain: ± 18 dB
Crossover Slope: 24 dB per octave
Crossover Type: 2-way Linkwitz-Riley
Programmable Crossover Frequency: 50 to 6500 Hz
PFM Filter Slope: 18 dB per octave
PFM Frequency: Programmable 15 to 100 Hz
Power Supply: Transformer-isolated
switch mode
Fuse Rating: 2 amps
Size: 1.25"h x 8.9" w x 6.9" d
Weight: 3 lbs
Balanced Input Yes
Ground Isolation Jumpers Yes
Country of origin: USA
