Channels: 4
Class: D
Efficiency: 84%
Hi Level Input: Yes
Low Level Input: Yes
Digital Input: No
Power supply voltage / fuse: 11 - 15 VDC
Operating power supply voltage: 6.5 - 17.5 VDC
Idling current: 0.004 A
Idling current when off: 0.6 mA
Consumption @ 14.4 VDC, 2Ω, Max Musical Power: 25 A
Remote OUT: 6.5 -15 VDC (150 mA)
Remote IN: 4 - 15 VDC (1 mA)
ART: Automatic Remote Turn on/off from OUTPUT BTL speakers (Selectable) 1.5 VDC
Distortion - THD @ 100 Hz, 4Ω, 70% Rated Power: 0,03%
Bandwidth A (-3 dB, 2 VRMS, 4 Ω): 10Hz - 40kHz
S/N ratio A (A weighted @ 1 V): 102 dBA
Damping factor A (1 kHz, 4Ω, 2 VRMS): 95
Input sensitivity Pre-In: 0.6 - 6 VRMS
Input sensitivity Speaker-In: 2.2 - 22 VRMS
Total Power RMS: 600 W
Minimum load impedance: 2Ω
Output Power (RMS) @14.4 VDC, 1% THD: 4Ch @ 4Ω: 90 W x 4,
4Ch @ 2Ω: 150 W x 4
2Ch (bridge) @ 4Ω: 300 W x 2
Adjustable Crossover No
CEA SPECIFICATIONS
Output power @ 4Ω, 1% THD+N, 14.4 V 90 W x 4
SN ratio (ref. 1W output) 81 dBA
INPUTS
Input Type: Pre-In / Speaker-In
Remote Sub Volume: ±12 dB
Fuse: 1 x 30 A
Weight: 1.49 kg
