Distortion - THD @ 1 kHz, 4Ω, 70% Rated Power: 0.03 %
Bandwidth @ -1.5 dB: 10Hz - 600 Hz
Damping factor @ 1 kHz, 4Ω, 2 VRMS: 140
S/N ratio (A weighted @ 1 V Input) Master Input: 105 dBA
S/N ratio (A weighted @ 1 V Input) Optical Input: 105
Total Power RMS: 1000 W
Minimum load impedance: 1Ω
Output Continuous Power (RMS) @14.4 VDC, 1% THD 1Ch @ 4Ω: 600 W x 1
1Ch @ 2Ω: 1000 W x 1
1Ch @ 1Ω: 1200 W x 1
Adjustable Crossover: Yes
Channels: 1
Class: D-Class
Efficiency: 84 %
Power supply voltage/fuse: 11 - 15 VDC / 2 x 35A
Operating power supply voltage: 6.5 - 17.5 VDC
Idling current: 1.15 A
Consumption @ 14.4 VDC, 2Ω, Max Musical Power: 65 A
Remote IN: 4 - 15 VDC (1 mA)
Remote OUT: 6.5 - 15 VDC (150 mA)
ART - Automatic Remote Turn on/off from OUTPUT BTL speakers: 1.5 VDC
Efficiency Rated Power: 84%
CEA Specifications
Output power @ 4Ω, 1% THD+N, 14.4 V: 600 W
SN ratio (ref. 1W output): 81 dB
Pre-In Inputs: 0.6 - 6 VRMS (15 KΩ Imp.)
Digital Input: Yes
Pre Outputs: 6
Hi Level Inputs: 8
Low-Level Inputs: 8
Speaker-In Inputs: 2.2 - 22 VRMS (5 Ω Imp.)
Digital IN 1 x Optical S/PDIF; Max 192 kHz / 24 bit + 1 x Optical/Coaxial S/PDIF with optional F2O card
Filter type: Full / High-Pass / Low-Pass / Band-Pass
Filter mode and slope: Linkwitz-Riley @ 12/24/36/48 dB/Oct.
Butterworth @: 6/12/18/24/30/36/42/48 dB/Oct.
Bessel @: 6/12/18/24/30/36/42/48 dB/Oct.
Chebyshev: @ 6/12/18/24/30/36/42/48 dB/Oct.
QLP @: 6 dB/Oct.
Crossover frequency: 20 Hz - 20 kHz
Analog Input Equalizer (20 - 20k Hz): 12 Biquad + Delay
Time Alignment Distance: 0 - 510 cm / 0 - 200.8 inches
Time Alignment Delay: 0 - 15 ms
Input Output Real Time Audio Monitor: RTA
Size: 240 x 47 x 156 / 9.44 x 1.85 x 6.14
Weight: 1.95 kg
