Channels: 4 - 3 - 2
Amp class: AB
Nominal power supply voltage (fuse): 11 - 15 VDC (2 x 20 A)
Operating power supply voltage: 6.5 - 16.5 VDC
Idling current: 0.8 A
Standby current draw: 5 uA
Consumption, MIN load impedance (Max Musical Power): 24 A
Remote IN: 4 - 15 VDC (1.5 mA)
ART - Automatic Remote Turn on/off from SPK-IN (BTL radio only): 1.5 VDC
Efficiency: 59%
Distortion - THD @ 100 Hz, 70% Rated Power: 0.015%
Damping factor @ 1 kHz, 1W: 105
Bandwidth @ -3 dB: 10Hz - 45kHz
S/N ratio (A-weighted @ 1 V Input): 100 dBA
Minimum load impedance
@ 4 Ch: 2 Ω
@ 3 Ch: 2 Ω + 2 Ω + 4 Ω
@ 2 Ch: 4 Ω
Adjustable Crossovers yes
Output Power
Output power (RMS) @ 1% THD:
4Ch @ 4Ω 60 W x 4
4Ch @ 2Ω 85 W x 4
3Ch @ 4Ω 60 W x 2 + 170 W x 1
3Ch @ 2Ω / 4Ω 85 W x 2 + 170 W x 1
2Ch @ 4Ω 170 W x 2
Output Power (RMS) @ 14.4 VDC, THD 10%:
4Ch @ 4Ω 75 W x 4
4Ch @ 2Ω 105 W x 4
3Ch @ 4Ω 75 W x 2 + 210 W x 1
3Ch @ 2Ω / 4Ω 105 W x 2 + 210 W x 1
2Ch @ 4Ω 210 W x 2
Total Power 840 W
INPUTS / FILTERS
Inputs Pre-In / Speaker-In
Pre Out Full Range - (Front)
Pre-In sensitivity 0.32 - 8 VRMS
Speaker-In sensitivity 1.6 - 40 VRMS
Front Ch Hi-Pass Full / 50-4000Hz 12dB/Oct.
Front Ch Lo-Pass Full / 50-4000Hz 12dB/Oct.
Rear Ch Hi-Pass Full / 50-4000Hz 12dB/Oct.
Rear Ch Lo-Pass Full / 50-4000Hz 12dB/Oct.
Bass Boost 50Hz 0 - 9 dB
